UHF RFID Android Reader
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

UHF RFID Android Reader

Available:In Stock
  • Extremely Stable Performance
  • High-Speed Data Communication
  • Rugged Ergonomic, Over-molding Design with Extremely Stable Hardware Display
  • High-Efficiency Operating Style
  • High Accuracy and Long Reading Distance
  • Highly Customized Structure
  • Quick-Charging
  • Perfect Service


Buy In Bulk ContactUs +91 9765629111

X
Rs. 0.00

Barcode Scanner Handheld UHF RFID Android Reader extends Handheld-Wireless product serials into Android OS 7.0 with 4G high-speed network communication with a pistol grip. Inside the compact handheld device, sealing level of IP65 water/dustproof, 1.5m/4.5ft drop survival, ergonomic design, over-molding structure, quick- charging technology, large built-in battery of 8000mAh, and 5.0 inch tough Glass 3 9H screen are all equipped to ensure performance. Latest 1.3GHz quad-core processor 2GB RAM/16GB ROM and up to 128GB expansion are all designed to boost up experience level.

Barcode Scanner Handheld UHF RFID Android Reader extends Handheld-Wireless product serials into Android OS 7.0 with 4G high-speed network communication with a pistol grip. Inside the compact handheld device, sealing level of IP65 water/dustproof, 1.5m/4.5ft drop survival, ergonomic design, over-molding structure, quick- charging technology, large built-in battery of 8000mAh, and 5.0 inch tough Glass 3 9H screen are all equipped to ensure performance. Latest 1.3GHz quad-core processor 2GB RAM/16GB ROM and up to 128GB expansion are all designed to boost up experience level.

Display  5.0 inch Glass 3 9H TFT-LCD(720×1280)touch screen with backlight
 Keypads  3 TP keys, 6 function keys, 4 side buttons
 Battery  Rechargeable li-ion polymer, 3.7V, 8000mAh
 Drop Specifications  5ft./1.5 m drop to concrete across the operating temperature range
 Sealing  IP65, IEC compliance
 ESD  ±15kv air discharge, ±8kv direct discharge
 SDK  HHW Software Development Kit
 Language  Java
 Environment  Android Studio or Eclipse
 GPS  GPS(embedded A-GPS), accuracy of 5 m
 1D barcode  1D laser engine:Symbol SE955/Honeywell N431X



Symbologies:All major 1D barcodes

 2D barcode  2D CMOS Imager:Honeywell N6603



Symbologies:PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro   QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Japan Postal,   Dutch Postal. etc.

 RFID LF  Frequency:125KHz/134.2KHz(FDX-B/HDX) Protocol:ISO 11784&11785



R/W Range:2cm to 10 cm

 RFID HF  Frequency:13.56MHz Protocol:ISO 14443A&15693



R/W Range:2cm to 8 cm

 RFID UHF  Frequency:865~868MHz or 920~925MHz Protocol:EPC C1 GEN2/ISO 18000-6C



Antenna Gain:Circular antenna(3dBi)

R/W Range:Default: 6 m to 7 m(tags and environment dependent)

R2000 UHF Reader: 5 m to 7 m(tags and environment dependent)

ThingMagic M6E Micro: 6m to 8 m(tags and environment dependent)
