TSL 1128 Bluetooth UHF RFID Reader | 865-868MHz | Micro USB
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great
Categories

TSL 1128 Bluetooth UHF RFID Reader | 865-868MHz | Micro USB

Add Your Review
Available:In Stock


Rs. 120,610.00

(Tax & Fright Extra)

Price Excluded GST Tax & Shipping

  • 1128 Bluetooth UHF RFID Reader
  • Dimensions (LxWxH): 16.0 cm x 7.7 cm x 16.9 cm
  • Weight:375 g / 13.2 oz (including battery & trigger handle).
  • Power:Removable, rechargeable 3.7V, 2400mAh, 8.9Wh Lithium Polymer battery pack.
  • RFID: EPC Class 1 Gen 2.
  • 1 Year Warranty in all products
  • SDK and APIs are available for support
X

The new 1128 Bluetooth UHF RFID Reader is designed to read and write to EPC Class 1 Gen 2 (ISO18000-6C) UHF transponders and communicates with a variety of host devices via Bluetooth wireless technology.  With its Impinj R2000 core and range of interchangeable high-performance antennas 1128 performs like no other reader, giving the user the highest levels of flexibility currently available in today’s market.  The reader can be configured with class-leading high-performance 2D data scanning to bring unparalleled data collection capabilities to connected devices.

Multi-Platform 1128 brings high-performance UHF RFID scanning to devices running a wide range of Operating Systems including Android, iOS, Windows Mobile, WinCE, and Windows XP/Vista/7/8. The 1128 Bluetooth UHF RFID Reader is compatible with Bluetooth-enabled host devices including enterprise handhelds, consumer phones, touchscreen MP3 players, tablets, and PCs. Almost any small device can be attached to the 1128 Bluetooth UHF RFID Reader using a combination of the 1128 Accessory Mount and commercially available device cases.  The Accessory Mount securely holds the device in place, yet slides on and off the reader's body in one quick action.



The new 1128 Bluetooth UHF RFID Reader is designed to read and write to EPC Class 1 Gen 2 (ISO18000-6C) UHF transponders and communicates with a variety of host devices via Bluetooth wireless technology.  With its Impinj R2000 core and range of interchangeable high-performance antennas 1128 performs like no other reader, giving the user the highest levels of flexibility currently available in today’s market.  The reader can be configured with class-leading high-performance 2D data scanning to bring unparalleled data collection capabilities to connected devices.

Multi-Platform 1128 brings high-performance UHF RFID scanning to devices running a wide range of Operating Systems including Android, iOS, Windows Mobile, WinCE, and Windows XP/Vista/7/8. The 1128 Bluetooth UHF RFID Reader is compatible with Bluetooth-enabled host devices including enterprise handhelds, consumer phones, touchscreen MP3 players, tablets, and PCs. Almost any small device can be attached to the 1128 Bluetooth UHF RFID Reader using a combination of the 1128 Accessory Mount and commercially available device cases.  The Accessory Mount securely holds the device in place, yet slides on and off the reader's body in one quick action.



Physical and Environmental Characteristics

Dimensions (LxWxH):

16.0 cm x 7.7 cm x 16.9 cm – Trigger handle.

16.0 cm x 7.7 cm x 9.7 cm – Slimline grip.

Weight:

375 g / 13.2 oz (including battery & trigger handle).

User input:

Trigger button.

User feedback:

Speaker, vibration motor, LED.

Power:

Removable, rechargeable 3.7V, 2400mAh, 8.9Wh Lithium Polymer battery pack.

Minimum operating time:

Light use:

6 hrs

Moderate use:

3.5 hrs

Heavy use:

1.5 hrs

Enclosure materials:

Polycarbonate.

Performance Characteristics

RFID engine:

TSL® custom module with embedded Impinj R2000.

Communication protocols:

TSL® ASCII 2.0 parameterised command set

Impinj binary.

Memory:

Optional Micro SD card (maximum 32GB capacity supported).  Up to 500 million date and time stamped EPCs can be stored on a 32GB Micro SD card (separate purchase from alternative supplier).

Compatible Host devices (Bluetooth®):

Any Bluetooth® Host5 supporting the Serial Port Profile (SPP) or Human Interface Device (HID) profile (Android, iOS, Linux, Mac, Windows). See Bluetooth® Mode Comparison.

Compatible Host devices (USB):

Any USB host with FTDI VCP driver support (Windows, Linux, Mac, Android).

Environmental

Operating Temp.:

-10°C to 40°C (14°F to 104°F).

Charging Temp.:

5°C to 40°C (41°F to 104°F).

Storage Temp.:

Less than 1 month at -20°C to +45°C (-4°F to 113°F).

Less than 6 months at -20°C to +35°C (-4°F to 95°F).

Humidity:

5% to 85% non-condensing.

Drop Spec:

Multiple drops to concrete: 4 ft./1.2 m ambient, 3ft / 0.9m across the operating temperature range.

Tumble:

500 0.5 metre tumbles at room temperature (1,000 cycles).

Environmental Sealing:

IP54.

Electrostatic Discharge (ESD):

± 15kVdc air discharge;  ± 8kVdc contact discharge.

MIL-STD 810F:

Meets and exceeds applicable MIL-STD 810F for drop, tumble and sealing.

RFID Performance

Standards supported:

EPC Class 1 Gen 2.

Nominal read range:

Up to 7m (23ft).

Nominal write range:

Up to 2m (6.5ft).

Field:

150-degree forward facing (approx.) measured from front of device.

Antenna:

Detachable, Circularly Polarized with optional 2D scanner.

Frequency Range:

EU: 865-868MHz; US: 902-928MHz.

See datasheet for other regions.

Maximum Output Power:

Up to 29 dBm (region dependent)

+ 3.0 dBiC Antenna

Antenna options:

High Performance CP.

High Performance CP with 2D Imager.

Barcode Scanning

Optional 2D Barcode Engine:

Optional TSL® custom 2D Barcode Scan Engine module.

Sensor Resolution:

1280 x 960 pixels, rolling shutter.

Field of View:

Horizontal: 44.5°, vertical: 33.5°

Focal Distance:

From front of engine: 15.24 cm (6 in.)

Aiming LED:

Green LED.

Illumination:

1 warm white LED.

Symbologies Supported:

1D: All major codes

2D: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX).

Communication

Bluetooth®:

Bluetooth® Version 2.1.

Bluetooth® Frequency Range:

2.4 – 2.4835 GHz.

Bluetooth® Profiles:

SPP Profile, HID Profile, Apple iAP.

Bluetooth® Power:

Class 2.

Bluetooth® TX Power:

3 dBm.

Bluetooth® Range7:

30 m.

Bluetooth® Pairing:

PIN, Simple Secure Pairing, NFC OOB Pairing.

Peripherals and Accessories

External interface:

MicroUSB connector for battery charging, and USB connectivity.

USB operating modes:

Tethered for real time data capture in conjunction with SmartWedge software. Download of stored scan data.

Optional charger:

TSL® 2136 4-Slot desktop charger.

Other Accessories:

Adapter mounts are available for a variety of smartphones handheld terminals.

Slimline Grip, Trigger Handle.

Regulatory

Regions

EU (CE), USA (FCC), Canada, Australia and more (see datasheet for details)

FCC ID

S6J1128

IC

8948A-1128

EMC

EN 55032:2015 +A11:2020
EN 55035:2017 +A11:2020
47 CFR Part 15B
ICES-003:2020 Issue 7

RF

EN 300 328 V2.2.2
EN 302 208 V3.2.0
EN 301 489-1 V2.2.3
EN 301 489-3 V2.1.1
EN 301 489-17 V3.2.4
47 CFR Part 15C 15.247
RSS-247 Issue 1

Electrical Safety

IEC 62368-1:2018
EN 62368-1:2020 +A11:2020
UL 62368-1:2019
CAN/CSA C22.2 No. 62368-1:19

Environmental

2011/65/EU (RoHS 2) Restriction of the use of certain Hazardous Substances in electrical and electronic equipment

2015/863 (RoHS 3) Amendment to Annex II of 2011/65/EU
