Barcode Scanner Handy LS2208
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

Barcode Scanner Handy LS2208

Available:In Stock
  • Model no. : LS2208
  • Types of Opration : 1D Laser
  • Scanning Type : Single line
  • Connectivity Type : USB Cable w/ Stand
  • Reading Range : 100 scans per second typical


Rs. 0.00

(Tax & Fright Extra)

Buy In Bulk ContactUs +91 9765629111

X

The affordable LS2208 Handheld Barcode Scanner provides fast, reliable scanning in an ergonomic, lightweight form. The wide working range —from near-contact to 17 inches — makes this device ideal for retail, hospital, education or government settings. Multiple on-board interfaces ensure integration with a variety of host systems. Durable, single-board construction. Meets stringent 5-ft drop tests. Scratch-resistant tempered glass exit window. Is designed for continuous use. Accurate first-time capture of 1D bar codes. Increased productivity, resulting in shorter check-out lines. Wide working range. Delivers optimal performance to 17 in (43 cm). Multiple on-board interfaces. Simplify installation and integration and ensures future compatibility. Plug-and-play, with universal cable. Means rapid deployment, with a single cable connecting to any computing environment. Intuitive design. Minimizes setup and training time. Ergonomic, lightweight design. Reduces user fatigue with sleek, balanced form for maximum comfort and productivity. Hands-free Intelligentsia. Enables presentation scanning and easy switching between hands-free and handheld modes. Advanced Data Formatting (ADF)Enables users to modify data prior to sending to host computer, reducing costly modifications to the host software. Scan pattern-Single line. Depth of field-From to 17 in./43 cm on 100% UPC./EAN symbols. Minimum resolution-20% minimum reflective difference. Decode capability-1D, See data sheet for full list of supported symbolizes. Interfaces supported-IBM, Keyboard wedge, RS-232, Synapse, USB, Wand. Technology-Laser. Pitch2-2 +/-65 degrees. Roll (Tilt) 3-1 +/-30 degrees. Skew (Yaw)4- 3 +/-60 degrees .

The affordable LS2208 Handheld Barcode Scanner provides fast, reliable scanning in an ergonomic, lightweight form. The wide working range —from near-contact to 17 inches — makes this device ideal for retail, hospital, education or government settings. Multiple on-board interfaces ensure integration with a variety of host systems. Durable, single-board construction. Meets stringent 5-ft drop tests. Scratch-resistant tempered glass exit window. Is designed for continuous use. Accurate first-time capture of 1D bar codes. Increased productivity, resulting in shorter check-out lines. Wide working range. Delivers optimal performance to 17 in (43 cm). Multiple on-board interfaces. Simplify installation and integration and ensures future compatibility. Plug-and-play, with universal cable. Means rapid deployment, with a single cable connecting to any computing environment. Intuitive design. Minimizes setup and training time. Ergonomic, lightweight design. Reduces user fatigue with sleek, balanced form for maximum comfort and productivity. Hands-free Intelligentsia. Enables presentation scanning and easy switching between hands-free and handheld modes. Advanced Data Formatting (ADF)Enables users to modify data prior to sending to host computer, reducing costly modifications to the host software. Scan pattern-Single line. Depth of field-From to 17 in./43 cm on 100% UPC./EAN symbols. Minimum resolution-20% minimum reflective difference. Decode capability-1D, See data sheet for full list of supported symbolizes. Interfaces supported-IBM, Keyboard wedge, RS-232, Synapse, USB, Wand. Technology-Laser. Pitch2-2 +/-65 degrees. Roll (Tilt) 3-1 +/-30 degrees. Skew (Yaw)4- 3 +/-60 degrees .

General

Series Symbol
Model LS2208
Part Number LS2208-SR20007R-NA
Form Factor Handheld
Connectivity Corded
Scan Engine 1D Laser

Connectivity


Included Cables USB Cable w/ Stand
Interfaces Supported USB, RS232, Keyboard Wedge, IBM 468x/9x

Scan Performance


Light Source 650 nm Laser Diode Class 2
Imager Field of View N/A
Resolution Minimum Element Resolution Code 39: 3.0 mil
Pitch +/- 65 degree
Roll +/- 60 degree
Yaw +/- 10 degree
Scan Speed 100 scans per second typical
Print Contrast Ratio (Minimum) 20% minimum reflective difference
Decoding Capability Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma). Refer to Product Reference Guide for a complete list of symbologies

Electrical


Input Voltage 4.5 to 5.5 VDC host powered; 4.5 to 5.5 VDC external power supply
Current Operating: 175 mA (typical)
Standby: 90 mA (typical)

Mechanical


Color Twilight Black
Dimensions 6.00″ x 2.50″ x 3.34″
Weight 0.33 lb.
Drop Unit functions normally after repeated 5.00 ft. / 1.50 m drops to concrete
Ruggedness General Purpose
Antimicrobial N/A
