SRK-420 Impinj Fixed RFID Readers
- 2 and 4 antenna port configurations
- Power over Ethernet (PoE) and cellular modem connectivity
- Autopilot (automatically senses the environment and configures settings for best performance)
- Enterprise-class management and monitoring
- Support from industry-leading software vendors such as Microsoft and IBM.
Buy In Bulk ContactUs +91 9765629111
Impinj's Speedway Revolution Fixed RFID Readers and antennas deliver the performance, quality, and reliability necessary for robust RFID-based information you can count on. With its Autopilot, it adapts to any environment automatically. With high mean time between failure and a suite of supporting products and tools, Impinj Speedway readers are a powerful piece of every item visibility platform solution. \n \nOne of the most remarkable features of Impinj Speedway is Wi-Fi/Cellular modem connectivity making them Wi-Fi enabled & GSM/GPRS enabled as well.
Impinj's Speedway Revolution Fixed RFID Readers and antennas deliver the performance, quality, and reliability necessary for robust RFID-based information you can count on. With its Autopilot, it adapts to any environment automatically. With high mean time between failure and a suite of supporting products and tools, Impinj Speedway readers are a powerful piece of every item visibility platform solution. \n \nOne of the most remarkable features of Impinj Speedway is Wi-Fi/Cellular modem connectivity making them Wi-Fi enabled & GSM/GPRS enabled as well.
| Air Interface Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Antennas | 4 high performance, monostatic antenna ports optimized for Impinj reader antennas (RP TNC) |
| Transmit Power | • +10.0 to +30.0 dBm (PoE)
• +10.0 to +32.5 dBm (external universal power supply) |
| Max Receive Sensitivity | -82 dBm |
| Min Return Loss | 10 dB |
| Application Interface | EPC global Low Level Reader Protocol (LLRP) v1.0.1, Speedway Revolution SDK & EDK |
| Network Connectivity | 10/100BASE-T auto-negotiate (full/half) with auto-sensing MDI/MDX for auto-crossover (RJ-45) |
| Cellular Connectivity* | • Sierra Wireless AirLink PinPoint XT (CDMA or GSM connectivity with GPS data)
• Sierra Wireless AirLink Raven XT (CDMA or GSM connectivity) (* Available through Impinj-authorized partners) |
| IP Address | Configuration DHCP, Static, or Link Local Addressing (LLA) with Multicast DNS (mDNS) |
| Management Interfaces | • Impinj Web Management UI
• Impinj RShell Management Console using serial management console port, telnet or SSH • SNMPv2 MIBII • EPCglobal Reader Management v1.0.1 • Syslog |
| Reliable Firmware Upgrade | • Dual image partitions enable smooth transition to new firmware while the reader is still operating
• Scalable upgrade mechanism enables simultaneously scheduled upgrades of multiple readers • USB Flash Drive • Impinj Web Management UI |
| Management Console | • RS-232 using a standard Cisco-style management cable (DB-9 to RJ-45)
• Baud rate: 115200, Data: 8 bit, Parity: none, Stop: 1 bit, Flow control: none |
| USB | • USB 1.1 Device (Type B) and Host (Type A) ports
• USB Virtual COM Serial Port and USB drive support for embedded applications. |
| Environmental Sealing | IEC IP52 |
| Shock and Vibration | Mil-Std-810G Certified |
| Operating Temperature | -20 ºC to +50 ºC |
