SRK-SYMD6L UHF RFID Reader | Reading Range upto 6m | 865~868MHz | TCP/IP
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

SRK-SYMD6L UHF RFID Reader | Reading Range upto 6m | 865~868MHz | TCP/IP

Available:In Stock


Rs. 18,910.00

(Tax & Fright Extra)

Price Excluded GST Tax & Shipping

Click Here For Bulk Enquiry

+91 8411958300




info@srkinnovations.com

  • model Name: UHF RFID Reader SRK-SYMD6L
  • Weight : 1.5kg (include package)
  • Material : ABS+PC
  • Frequency : 865-868MHz/902-928MHz
  • Dimension : 210(L) x 210(W) x 70(H) mm
  • 1 Year Warranty in all products
  • SDK and APIs are available for support
X

UHF RFID Reader SRK-SYMD6L is a self-intellectual property; Support ISO18000-6B and ISO18000-6C (EPC C1G2) protocol tag 865~868MHz/902~928Mhz radio with 8dbi antenna, which can be used to read EPC C1G2 RFID and OSR reading function. The product features automatic running, interactive and trigger- activating work modes, low power consumption and plug & play interface. It supports RJ45, RS232, RS485 interfaces in addition to Wiegand interface.



UHF RFID Reader SRK-SYMD6L is a self-intellectual property; Support ISO18000-6B and ISO18000-6C (EPC C1G2) protocol tag 865~868MHz/902~928Mhz radio with 8dbi antenna, which can be used to read EPC C1G2 RFID and OSR reading function. The product features automatic running, interactive and trigger- activating work modes, low power consumption and plug & play interface. It supports RJ45, RS232, RS485 interfaces in addition to Wiegand interface.



Model No.

SRK-SYMD6L

Brand

SRK Innovations

Physical Parameter

Weight

1.5kg (include package)

Shell material

ABS+PC

Dimension

210(L) x 210(W) x 70(H) mm (Exclude bracket and external wires)

UHF RFID Performance Parameter

Frequency

865-868MHz/902-928MHz

Protocol

EPC C1 GEN2 /ISO18000-6C

Built-in antenna

6dBi circular polarization

Power

30dBm (adjustable by 1dBm step with Syrotech demo software)

R/W range

Read range 6~8m, write range >50cm (test tag: AZ9662Inlay)

Electric Parameter

Communication interface

RJ45, RS232, RS485, Wiegand, Trigger

Serial rate

9600~115200bps

RJ45 rate

10Mbps

GPIO

1 relay output, 1 trigger input

Reading Indicator

Buzzer

Power consumption

~1W

Working

220V AC input, +9V/3A adaptor DC output

Accessories

Standard

Bracket, Power supply
