UHF Integrated Reader ID-IF9A
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

UHF Integrated Reader ID-IF9A

Available:In Stock
  •  Automatic scan Com Port/Network
  •  Support firmware upgrade
  •  Support Export Config/Import Config
  •  Multiple country languages
  •  Global frequency(860-960MHz)
  •  Password mode
  •  Read specify tag
  •  Relay
  •  Data cache
  •  Multiple customizable communication protocols
  •  RSSI


Buy In Bulk ContactUs +91 9765629111

X
Rs. 0.00

UHF Integrated Reader ID-IF9A is a UHF high-performance integrated reader with an Automatic scan Com Port/Network and support firmware upgrade. \n \nThese RFID readers which are used for advanced automation and management system such as Automatic Time Attendance for Schools, Personnel Tracking in Manufacturing Plants, Library Security, Access Control, Toll plaza automation, parking automation, Hospital Management, Laundry Automation, Event Management, Logistics Management, and other customized automation process and solutions.

UHF Integrated Reader ID-IF9A is a UHF high-performance integrated reader with an Automatic scan Com Port/Network and support firmware upgrade. \n \nThese RFID readers which are used for advanced automation and management system such as Automatic Time Attendance for Schools, Personnel Tracking in Manufacturing Plants, Library Security, Access Control, Toll plaza automation, parking automation, Hospital Management, Laundry Automation, Event Management, Logistics Management, and other customized automation process and solutions.

Model No. IDTS – IF9
Chip Options ID – UR100



Impinj R2000

Pr9200

API Support ·         Windows platform – .net / .net core / C++ / Java SDK



·         Linux platform – C and Java SDK

·         Android platform – Java

Programming Functions ·        Automatic reading / White list



·        Match reading /  Data  filter IP

·        Server Listening

Physical Dimensions: 285mm(L)*285mm(W) Weight: 2.0 Kg



Housing Material: Die-cast aluminum + ABS

Reading clue: Buzzer , Green LED









RFID







Air Protocol: ISO / IEC18000-6B, 6C / EPC C1Gen2 , C2GEN2 optional



Frequency: USA: 902 MHz-928MHz (FCC part 15) EU: 865-868MHz (ETSI EN 302208) IND: 865 – 867 MHz (WPC Approved)

Supportable /optional: Russian / Japan / Korea / Malaysia / Thailand / other customizable
Output Power: 0dBm-33dBm (±1dBm) adjustable Reading Range: 0-20m(According to Tag & Environment)



Channel Bandwidth:200KHz

Anti-collision: RSSI / Multi-tag / Intensive inventory supportable Work Mode: Fixed / Hop frequency optional

Connectivity Rj45, RS-232, RS-485, USB Wiegand
Power Supply DC 9V – 24V / 2.5A (DC 9V ~ 30V,60W)
Mounting Bracket Included
Environmental Operating Temperature: -20 – +70°C
Storage Temperature: -40 – +85°C
Humidity: 5-90% non-condensing (+25°C)
Sealing IP65
