UHF RFID Reader SRK- SYLD15| Long Distance upto 15mts|865-868MHz
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

UHF RFID Reader SRK- SYLD15| Long Distance upto 15mts|865-868MHz

Available:In Stock
  • Model name: UHF RFID Reader SRK- SYLD15
  • Weight : 4.5kg (include package)
  • Shell material : ABS+PC
  • Frequency : 865-868MHz/902-928MHz
  • Communication interface : RS232, RS485


Rs. 0.00

(Tax & Fright Extra)

Buy In Bulk ContactUs +91 8411958300

X

UHF RFID Reader SRK- SYLD15 Self-intellectual property; Design based on Impinj R2000| with excellent anti-collision performance Support ISO18000-6B, ISO18000-6C(EPC C1G2)protocol tag;902~928MHz frequency band(frequency customization optional); FHSS or Fix Frequency transmission; RF output power up to 30dbm(adjustable);12dbi antenna optional with effect distance up to 15m*;Support auto-running, interactive and trigger- activating work mode; Low power dissipation with single +12DC power supply; Support RJ45, Rs232, RS485, USB, interface.



UHF RFID Reader SRK- SYLD15 Self-intellectual property; Design based on Impinj R2000| with excellent anti-collision performance Support ISO18000-6B, ISO18000-6C(EPC C1G2)protocol tag;902~928MHz frequency band(frequency customization optional); FHSS or Fix Frequency transmission; RF output power up to 30dbm(adjustable);12dbi antenna optional with effect distance up to 15m*;Support auto-running, interactive and trigger- activating work mode; Low power dissipation with single +12DC power supply; Support RJ45, Rs232, RS485, USB, interface.



Model no.

SRK- SYLD15

Brand

SRK Innovations

Physical Parameter

Weight

4.5kg (include package)

Shell material

ABS+PC

Dimension

445(L) x 445(W) x 40(H) mm (Exclude bracket and external wires)

UHF RFID Performance Parameter

Frequency

865-868MHz/902-928MHz

Protocol

EPC C1 GEN2 /ISO18000-6C

Built-in antenna

12dBi line polarization

Power

30dBm (adjustable by 1dBm step with demo software)

R/W range



Read range 15~20m, write range >50cm (test tag: AZ9662Inlay)

Electric Parameter

Communication interface

RS232, RS485, Wiegand, Trigger

Serial rate

9600~115200bps

GPIO

1 relay output, 1 trigger input

Reading Indicator

Buzzer

Power consumption

~1W

Working

220V AC input, +9V/3A adaptor DC output

Accessories

Standard

Bracket, Power supply

Shipping
