UHF RFID Cable Seal Tag
- Frequency: 860 – 960 MHz
- Protocol: EPC Class 1 Gen2 / ISO/IEC 18000-6C
- Material: ABS or polystyrene
- Reading Distance: 3 M
- They are effective for Logistics management, Asset tracking, Container seals, Electric/Water Meter management, Storage bins, Pallet management, etc.
Buy In Bulk ContactUs +91 9765629111
UHF RFID cable seals are ideal for sealing commercial containers – bags, bins or boxes – to prevent unauthorized access to contents while in storage or during distribution. Seal Tag units integrate powerful RFID chips with high durability components, and secure, tamper-evident fasteners. RFID cable seals or anti-tamper cable seals combine the mechanical security of traditional LEGHORN CABLE SEAL products together with the electronic security offered by the latest radio frequency-based automatic identification (RFID) techniques.
This is a High-Security Seal, Univocally identifies the container or the vehicle to which it is attached. It can be easily and reliably read by fixed reading units placed at transit gates or by handheld reading units manually operated by inspectors and give back its unique code as a basic RFID seal. When compared to standard RFID seals, tamper-evident RFID seals are able to permanently store into their memory the tamper event by activating a status bit named TAG TAMPER ALARM, thus providing immediate information about seal status at readings (tampered/not tampered);
UHF RFID cable seals are ideal for sealing commercial containers – bags, bins or boxes – to prevent unauthorized access to contents while in storage or during distribution. Seal Tag units integrate powerful RFID chips with high durability components, and secure, tamper-evident fasteners. RFID cable seals or anti-tamper cable seals combine the mechanical security of traditional LEGHORN CABLE SEAL products together with the electronic security offered by the latest radio frequency-based automatic identification (RFID) techniques.
This is a High-Security Seal, Univocally identifies the container or the vehicle to which it is attached. It can be easily and reliably read by fixed reading units placed at transit gates or by handheld reading units manually operated by inspectors and give back its unique code as a basic RFID seal. When compared to standard RFID seals, tamper-evident RFID seals are able to permanently store into their memory the tamper event by activating a status bit named TAG TAMPER ALARM, thus providing immediate information about seal status at readings (tampered/not tampered);
Radio Frequency specification OF RFID Cable Seals | |
Frequency: | 860 – 960 MHz – UHF EPC Global |
Reference RF Standard: | ISO/IEC 18000-6C |
RF Protocol: | EPC Class 1 Gen2 / ISO/IEC 18000-6C |
Technology: | Passive |
Mechanical specification | |
Material | Aluminum + ABS or polystyrene in accordance with Restriction of Hazardous Substances (RoHS) |
IP Protection | IP66 |
Operative Temperature | – 30°C / + 80 °C |
Storage Temperature | – 30°C / + 80 °C |
Weight | 50g |
ISO 17712:2013 | yes |
Electronic specification | |
Reading distance handheld reader | 3 m (depending on reader) (9′) |
Reading distance gate reader | 8 m (depending on reader) (26′) |
Read / write cycles: | 10000 |
Data retention: | 20 years |
Password protection: | yes |
Tamper Detection: | yes |
TID (tag unique identification): | yes |
S/N in memory (same of the seal): | yes |
