SRK- SYLD15L UHF RFID Reader | Long Distance upto 15mts | 865-868MHz | RS232 & TCP/IP
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

SRK- SYLD15L UHF RFID Reader | Long Distance upto 15mts | 865-868MHz | RS232 & TCP/IP

Available:In Stock


Rs. 22,790.00

(Tax & Fright Extra)

Price Excluded GST Tax & Shipping

  • Model Name : UHF RFID Reader TCP/IP
  • Frequency: 865-868MHz/902-928MHz
  • Dimension: 445(L) x 445(W) x 40(H) mm
  • Protocol: EPC C1 GEN2 /ISO18000-6C
  • Read range 15~20m
  • Reading Indicator: Buzzer
  • 1 Year Warranty in all products
  • SDK and APIs are available for support
X

UHF RFID Reader SRK- SYLD15L Self-intellectual property Design based on Impinj R2000| with excellent anti-collision performance Support ISO18000-6B, ISO18000-6C (EPC C1G2) protocol tag 902~928MHz frequency band(frequency customization optional) FHSS or Fix Frequency transmission RF output power up to 30dbm(adjustable) 12dbi antenna optional with effect distance up to 15m* Support auto-running, interactive and trigger- activating work mode Low power dissipation with single +12DC power supply Support RJ45, Rs232, RS485, USB, Wiegand interface.



UHF RFID Reader SRK- SYLD15L Self-intellectual property Design based on Impinj R2000| with excellent anti-collision performance Support ISO18000-6B, ISO18000-6C (EPC C1G2) protocol tag 902~928MHz frequency band(frequency customization optional) FHSS or Fix Frequency transmission RF output power up to 30dbm(adjustable) 12dbi antenna optional with effect distance up to 15m* Support auto-running, interactive and trigger- activating work mode Low power dissipation with single +12DC power supply Support RJ45, Rs232, RS485, USB, Wiegand interface.



Model

SRK- SYLD15L

Physical Parameter

Dimension

445(L) x 445(W) x 40(H) mm (Exclude bracket and external wires)

Weight

4.5kg (include package)

4.5kg (include package)

ABS+PC

UHF RFID Performance Parameter

Frequency

865-868MHz/902-928MHz

Protocol

EPC C1 GEN2 /ISO18000-6C

Built-in antenna

12dBi line polarization

Power

30dBm (adjustable by 1dBm step with demo software)

R/W range

Read range 15~20m, write range >50cm (test tag: AZ9662Inlay)

Electric Parameter

Communication interface

RJ45, RS232, RS485, USB, Wiegand, Trigger

Serial rate

9600~115200bps

RJ45 rate

10Mbps

GPIO

1 relay output, 1 trigger input

Reading Indicator

Buzzer

Power consumption

~1W

Working

220V AC input, +9V/3A adaptor DC output



Standard

Bracket, Power supply

Index of Protecon

IP65
